Solis Three-Phase Inverter for Energy Storage with High Voltage

The S6-EH3P(30-50)K-H-ND series three-phase inverters for energy storage are tailored for commercial solar energy storage systems. These products support an independent generator port and parallel operation of multiple inverters.

With 4 MPPTs and an input current capacity of 40A/MPPT, they maximize the benefits of rooftop solar panels. These products also feature independent generator ports, high charge and discharge capacity, and various flexible load options, including switching to UPS level. They easily adapt to three-phase unbalanced loads and half-wave loads, ensuring a highly reliable power supply.

Features:

• - 2 seconds of 160% overload capacity
• - Supports a maximum input current of 20A - ideal for all high-efficiency PV modules regardless of brand
• - Real-time battery monitoring, remote upgrade, and battery healing function to extend battery life
• - Supports peak load reduction in “Self-Use” and “Generator” modes
• - Supports unbalanced and half-wave loads on both the grid and backup port
• - Wide battery voltage range - compatible with most common high-voltage lithium batteries
• - Battery charge/discharge current 140A/70A+70A - suitable for 280Ah cell standard 0.5C application
• - Supports 200% DC/AC ratio - maximum solar charging and long backup
• - With 4 MPPTs and an input current capacity of 40A/MPPT for optimal solar efficiency
