Charge Amps Aura 2x22kW 4G – For public charging stations or individuals needing two charging points

Charge Amps Aura 4G offers the same reliable charging solution as Aura 2x22kW, with a built-in 4G modem for additional connectivity options. Perfect for locations with limited WiFi access, the charger can charge two vehicles simultaneously with up to 22 kW per outlet.

Features

• Built-in 4G modem: With a SIM card and two years of free usage, Aura 4G ensures reliable connectivity to cloud services, even where WiFi is lacking.
• Daisy chaining: Supports 16 mm² supply in and out of each unit as well as dual RJ45 ports for LAN connection.
• Industrial design: Durable and aesthetic, made from recycled aluminum.
• Load balancing: Optimizes power with built-in phase allocation and phase rotation for efficient charging.
• Flexible connection: Compatible with OCPP 1.6J, with adjustable power and load balancing between outlets.

Installation and Configuration

Aura 4G is designed for easy daisy chaining, making it ideal for larger facilities. It supports 4G connectivity and has dual RJ45 ports for LAN connection. Installers have free access to Charge Amps Academy for installation videos and guides.

Integrated Solutions and Connectivity

Aura 4G is compatible with OCPP 1.6J and can be connected to cloud services. With the built-in 4G modem, Aura 4G offers stable connectivity, even where WiFi is unavailable. The connection allows for monitoring and management via app or Charge Amps Cloud, as well as other third-party solutions.

Green Charging with Solar Panels

Charge Amps Aura is optimized for green charging, especially when used with Amp Guard as a power monitor. With the "Green Charging" function, users can charge their vehicles with electricity from solar panels, by adjusting the charging based on the produced solar energy.

Technical Specifications

• Power: 2 x 22 kW
• Current: 6-32 A
• Weight: 10 kg
• Dimensions: 367 x 159 x 405 mm
• Cable/Outlet: Outlet
• Number of phases: 3
• IP rating: 55
• Built-in energy meter: Yes
• Tax deduction: Yes
• Manufactured in: Sweden
• RFID: Yes
• Adjustable power: Yes
• Load balancing: Between outlets
• OCPP: Yes, 1.6J
• 4G: Yes
• RF technology: GSM, GPRS, EDGE, UMTS/HSPA+, LTE
• Max RF power: 32 dBm@GSM, 24 dBm@WCDMA, 23 dBm@LTE
• SIM card: Standard SIM
• App connection: Yes
• WiFi: Yes
• Charging standard: Mode 3
• Operating temperatures: -30 °C to +45 °C
• Residual current device: RCD Type B built into each outlet
• Warranty: 3 years
